Li-ion 11.1v 5200mAh 3s2p 18650 lithium battery pack for solar light
Voltage：11.1V
Capacity:5200mAh
Cell type: ICR18650-2600mAh cell
Specification:
| Model | 18650-3S2P |
| Nominal voltage | 11.1V |
| Nominal capacity | 5200mAh |
| Size | customized |
| Max charge current | 0.5C |
| Charging method | Constant current 1C to 12.6V,then charge with constant voltage 12.6V till charge current less than 0.01C |
| Max discharge current | 1C |
| Discharge cut-off voltage | 7.5V, the over-discharge detection voltage of PCM |
| Operating environment | Charging, 0°C ~ 45°C ; 65±20%RH; Discharging, -20°C~60°C ; 65±20%RH |
| Storage environment | -20°C~45°; 65±20%RH; |
| Lifespan (80% Prime Capacity) | >500times |
| Charging Attention | It is dangerous that charging with higher current or voltage than Product Specification may cause damage to the cell electrical, mechanical safety performance. |
Product Advantages:
1) Green product
2) Long standby time
3) One year warranty
4) Excellent safety performance
5) Excellent storage performance and low self-discharge rate
6) Short circuit testing passed
7) Overcharge testing passed
8) Over discharge testing passed
9) 150C thermal shock test passed
10) 1.2m drop testing passed
Spotlight:
1. Provide both single cells and battery packs
2.100% inspection before delivery
3. Inspects inner resistance, discharge platform and self-discharge
4. IEC standard, capacity ranges from 120mAh to 200Ah
5. Manufacturer of 18650 lithium ion battery, lithium polymer battery etc.
6. Established quality control systems under ISO9001
7. Customized packs, tags, labels, plugs, connectors, over current protection, temperature cont8.l protection are available
Product application
Light: headlamp, emergency light, sloar flashlight, searchlight, lanten,bicycle light, LED light, high-end flashlight, high power flashlight, bright flashlight.
2.Outdoor sports products: camping light, mountain bike light, solor emergency light, self-defense flashlight,
3.Customer electronics: MPS, Tablet PC. laptop, Bluetooth earphone, power bank, portable DVD player,
speaker, microphone, sound equipment, audio, Digital camera, vidican.
4.Home appliances products: electric mop, electric vacuum cleaner, electric children toys, electric shoes,
electric blanket.
5.Medical devices
6.Instruments and meters: water meter, gas meter.
7.Electric transportation vehicles: electric bike, electric car, e-scooter, electric motor, electric trolley, electric cart.
8.Power tools: electric drill, mower
9.UPS, backup energy, storage energy.
Walkie talkie, smart watch, headset, set top box, bluetooth speaker, beauty instrument, Miner’ lamp, electric toy, emergency phone,
