Specification:
Operates from 4.8-60V
0V with optional auxiliary battery.
Measures 0-150A,resolution 0.01A
0-60V,resolution 0.01V
0-6554W,resolution 0.1W
0-65Ah,resolution 0.001Ah
0-6554Wh,resolution 0.1Wh
16×2,backlit LCD display
Features:
1, Digital LCD screen gives clear crisp number readings.
2, Connecting load end to the battery provides real-time battery charging reading.
3, Measure energy(wh),charge(ah), power(w),current(A) and voltage(V).
4, Connector to use an optinal receiver battery for measurement down to 0V
5, Accurate & precise 0.01 A cuurrent and 0.01 V voltage resolutions.
6, Measures peak Amps, peak Watts(except for Doc Wattson) and Voltage minimum(sag).
7, Rugged- handles 50A continuous and 150 A peak at 65V.
8, 14a ga., super fine stranded, high temperature, silicone rubber insulated wire.
9, Small & light with a tough plastic case available in several colors.
10, Acts like a wire so doesn’t affect model’s performance. Precision Alu-Chrom current sensing resistor, with only 0.001 Ohms resistance and circuitry that draws only 7 mA.
11, USes DSP to increase ADC resolution and differential measurement amplifiers to increase noise immunity.
12, Factory calibration stores constants in EEP to compensate for component tolerances.
13, Powerful , 8 MIPS micro-controller .
