Specification:
Lipo NiCad NiMH 2S-6S imax b6 lipo battery balance charger
Operation voltage range : DC 10.0 ~ 20.0 Volt
Circuit power : AC to DC adaptor (DC 10.0 ~ 20.0V / 6A)
Max. charge power 80W
Max. discharge power 10W
Charge current range : 0.1~6.0A
Discharge current range : 0.1~2.0A
Current drain for balancing Li-Po : 300mAh/cell
NiCd / NiMH battery cell count : 1~15 cell
Li-Ion / Polymer cell count : 1~6 series
Pb battery voltage : 2V~20V
Weight : 277g (Net Weight)
Dimensions : 133 x 87 x 33 mm
Advanced Features
Intelligent Battery Recognition: Automatically detects the battery type and number of cells, simplifying the charging process.
Battery Voltage Balance Function: Ensures each cell in a battery pack is charged to the same voltage level, enhancing battery performance and longevity.
Temperature Protection: Equipped with a temperature sensor interface (some versions have built-in temperature detection) to prevent overheating and ensure safe charging.
LCD Display: Features a dot matrix LCD screen with backlighting that displays charging status, operation menus, and error messages.
User-Friendly Interface: Easy-to-navigate menus and settings make it straightforward to configure and monitor the charging process.
Multi-functional and Portable: Suitable for a wide range of battery types and sizes, and its compact design makes it easy to transport.
Safety Features: Incorporates various safety protections, such as overcharge protection, short circuit protection, and reverse polarity protection.
